Description
The RED Komodo-X advances the original Komodo with faster frame rates and a redesigned Super 35 sensor, in the same compact body.
The new global shutter sensor doubles top frame rates to 6K at 80fps and 4K at 120p, with improved colour science and shadow detail. A reinforced, tooless-locking Canon RF mount speeds up lens changes on set. Built-in Wi-Fi supports 1080p live streaming, and the expanded interface adds 12G-SDI output (up to 4K 60p) and a USB-C port with Ethernet offload.
Firmware version: v2.2.4 (released 18 May 2026) · Specs last verified against manufacturer's sheet: 18 July 2026
Sensor
| 19.9MP Super 35 global shutter CMOS, 27.03 x 14.26mm |
| 16.5 stops dynamic range |
Recording
| REDCODE RAW (HQ/MQ/LQ/ELQ), ProRes 422LT-4444XQ at 4K |
| Up to 6K/80fps, 5K/96fps, 4K/120fps, 2K/240fps |
Mount & Media
| Locking Canon RF mount |
| CFexpress Type B, up to 560MB/s |
Power & I/O
| 11-17V DC via 6-pin DC-IN, integrated V-Lock (Micro V-Lock batteries) |
| 12G-SDI (with 6G/3G/1.5G modes), 2.9″ 1440×1440 integrated touchscreen |
Body
| Weight | 2.62lb / 1.19kg (without body cap and media) |
|---|
| Dimensions | 129.37 x 101.26 x 95.26mm |
|---|
Download Spec Sheet (PDF)
